Cmd. Sub cmd. Data Description
1A 05 0101 00 Send/read Normal selection for paddle
polarity
01 Send/read Reverse selection for paddle
polarity
0102 00 Send/read Straight selection for keyer
type
01 Send/read BUG-Key selection for keyer
type
02 Send/read ELEC-Key selection for keyer
type
0103 00 Send/read Mic. up/down keyer OFF
01 Send/read Mic. up/down keyer ON
0104 00 Send/read1275HzselectionforRTTY
mark frequency
01 Send/read1615HzselectionforRTTY
mark frequency
02 Send/read2125HzselectionforRTTY
mark frequency
0105 00 Send/read170HzselectionforRTTYshift
width
01 Send/read200HzselectionforRTTYshift
width
02 Send/read425HzselectionforRTTYshift
width
0106 00 Send/readNormalselectionforRTTY
keying polarity
01 Send/readReverseselectionforRTTY
keying polarity
0107 00 Send/readRTTYdecodeUSOSOFF
01 Send/readRTTYdecodeUSOSON
0108 00 Send/read “CR,LF,CR+LF” selection for
RTTYdecodenewlinecode
01 Send/read“CR+LF”selectionforRTTY
decode new line code
0109 00 Send/read 2 lines selection for number of
RTTYdecoderline
01 Send/read 3 lines selection for number of
RTTYdecoderline
0110 00 Send/read Scan speed Low
01 Send/read Scan speed High
0111 00 Send/read Scan resume OFF
01 Send/read Scan resume ON
0112 00 Send/read OFF selection for MAIN DIAL
function during a scan
01 Send/read Up/Down selection for MAIN
DIAL function during a scan
0113 0000 to
0255
Send/read NB level (HF/50 MHz)
(0000=0%to0255=100%)
0114 00 to 09 Send/read NB depth (HF/50 MHz)
(00=1to09=10)
0115 0000 to
0255
Send/read NB width (HF/50 MHz)
(0000=1to0255=100)
0116 0000 to
0255
Send/read NB level (144 MHz)
(0000=0%to0255=100%)
0117 00 to 09 Send/read NB depth (144 MHz)
(00=1to09=10)
0118 0000 to
0255
Send/read NB width (144 MHz)
(0000=1to0255=100)
0119 0000 to
0255
Send/read NB level (430 MHz)
(0000=0%to0255=100%)
0120 00 to 09 Send/read NB depth (430 MHz)
(00=1to09=10)
0121 0000 to
0255
Send/read NB width (430 MHz)
(0000=1to0255=100)
0122 0000 to
0255
Send/read NB level (1200 MHz)
(0000=0%to0255=100%)
0123 00 to 09 Send/read NB depth (1200 MHz)
(00=1to09=10)
0124 0000 to
0255
Send/read NB width (1200 MHz)
(0000=1to0255=100)
Cmd. Sub cmd. Data Description
1A 05 0125 0000 to
0255
Send/read VOX gain
(0000=0%to0255=100%)
0126 0000 to
0255
Send/read ANTI-VOX gain
(0000=0%to0255=100%)
0127 00 to 20 Send/read VOX delay time
(00=0.0sec.to20=2.0sec.)
0128 00 Send/read VOX voice delay OFF
01 Send/read Short selection for VOX voice
delay
02 Send/read Mid selection for VOX voice
delay
03 Send/read Long selection for VOX voice
delay
0129 0020 to
0130
Send/read BK-IN delay time
(0020=2.0dto0130=13.0d)
0130 0000 to
0255
Send/read MONITOR gain
(0000=0%to0255=100%)
0131 00 Send/read Standby Beep OFF
01 Send/read ON-1 selection for Standby
Beep
02 Send/read ON-2 selection for Standby
Beep
0132 00 Send/read Auto Reply OFF
01 Send/read Auto Reply ON
0133 00 Send/read PTT selection for DV Data TX
01 Send/read Auto selection for DV Data TX
0134 00 Send/read Auto selection for Digital Moni-
tor
01 Send/read Digital selection for Digital
Monitor
02 Send/read Analog selection for Digital
Monitor
0135 00 Send/read Digital RPT Set OFF
01 Send/read Digital RPT Set ON
0136 00 Send/read RX Call Sign Auto Write OFF
01 Send/read Auto selection for RX Call Sign
Auto Write
0137 00 Send/read RX RPT Call Sign Auto Write
OFF
01 Send/read Auto selection for RX RPT Call
Sign Auto Write
0138 00 Send/read DV Auto Detect OFF
01 Send/read DV Auto Detect ON
0139 00 Send/read Call Sign Edit Record OFF
01 Send/read Select selection for Call Sign
Edit Record
02 Send/read Auto selection for Call Sign
Edit Record
0140 00 Send/read Gateway Auto Set OFF
01 Send/read Auto selection for Gateway
Auto Set
0141 00 Send/read ALL selection for RX Record
(RPT)
01 Send/read Latest Only selection for RX
Record (RPT)
0142 00 Send/read RX Call Sign Auto Display OFF
01 Send/read Auto selection for RX Call Sign
Auto Display
0143 00 Send/read TX Call Sign Display OFF
01 Send/read UR selection for TX Call Sign
Display
02 Send/readMYselectionforTXCallSign
Display
0144 00 Send/read RX Message Display OFF
01 Send/read Auto selection for RX Message
Display
0145 00 Send/read Scrolling speed slow
01 Send/read Scrolling speed fast
