Icom i9100

20
1
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
D Function keys on M1 (Menu 1) display
AGC KEY [AGC](F-1) (p. 72)
➥ Push to select the time constant of the AGC circuit.
➥ Hold down for 1 second to display the “AGC”
screen.
DUPLEX KEY [DUP](F-2) (p. 65)
➥ Push to select the duplex direction, or to turn OFF
the function.
•“DUP–”or“DUP+”isdisplayedduringduplexoperation.
➥ In the FM mode, hold down for 1 second to turn the
one-touch repeater function ON or OFF.
SPEECH COMPRESSOR KEY [COMP](F-3) (p. 80)
(Mode: SSB)
➥ Push to turn the speech compressor function ON
or OFF.
•“COMP”isdisplayedwhenthespeechcompressoris
ON.
➥ Hold down for 1 second to display the “COMP”
screen.
1
⁄4 TUNING FUNCTION KEY [
1
⁄4](F-3) (p. 39)
(Mode: SSB-D/CW/RTTY)
Push to turn the
1
⁄4 Tuning function ON or OFF.
•“ ” is displayed when the
1
⁄4 Tuning function is ON.
AFC KEY [AFC](F-3) (p. 69)
(Mode: FM/DV)
Push to turn the AFC function ON or OFF.
•“ ” is displayed when the AFC function is ON.
TRANSMISSION BANDWIDTH KEY [TBW](F-4)
(p. 80)
(Mode: SSB)
➥ Push to display the selected transmission band-
width.
➥ Hold down for 1 second to select the transmission
bandwidth.
 •Bandwidthisselectablefromwide(WIDE),middle(MID)
and narrow (NAR).
MEMORY KEYER MENU KEY [KEY](F-4) (p. 50)
(Mode: CW)
Push to display the “ KEY ” screen (memory keyer) or the
“ SEND ” screen(keyersend),dependingonthe“KEYER
1st Menu” option in the Set mode (p. 165) .
RTTY MENU KEY [RTTY](F-4) (p. 57)
Pushtodisplaythe“RTTY”screen.
TONE SQUELCH KEY [TON](F-4) (pp. 62–64)
(Mode: FM)
➥ Push to select a tone function between subaudible
(repeater) tone, tone squelch and DTCS code.
➥ Hold down for 1 second to display the “TON” screen
of the selected tone function.
DIGITAL SQUELCH KEY [DSQ](F-4) (p. 114)
(Mode: DV)
➥ Push to select a digital squelch function between
digital call sign squelch and digital code squelch.
➥ Hold down for 1 second to display the “DSQ” screen
(digital squelch).
BAND SCOPE FUNCTION KEY [SCP](F-5) (p. 70)
Push to display the “SCP” screen (band scope).
D Function keys on M2 (Menu 2) display
SCAN KEY [SCAN](F-1) (p. 147)
Push to display the “SCAN” screen.
MEMORY NAME KEY [MEM](F-2) (p. 143)
Push to display the “MEM” screen (memory name
edit).
SWR GRAPH FUNCTION KEY [SWR](F-3) (p. 84)
Push to display the “SWR” screen.
TONE CONTROL SET MODE KEY [TCON](F-4)
(p. 169)
Push to enter the Tone Control Set mode.
VSC FUNCTION KEY [VSC](F-5) (p. 146)
(Mode: SSB/AM/FM)
Push to turn the VSC (Voice Squelch Control) function
ON or OFF.
•“ ” appears when the VSC function is ON.
The optional UT-121 is required for DV mode operation.
