Icom IC-7400 - Basic Operation; Initial Power-Up and Reset

Before first applying power, make sure all connections
required for your system are complete by referring to
Chapter 2. Then, reset the transceiver using the fol-
lowing procedure.
NOTE: When first applying power or when operat-
ing in cold environments, the display may flicker or
appear faint. This is normal and will disappear once
the transceiver has warmed up.
q Make sure the transceiver power is OFF.
w While pushing [M-CL] and [F-INP], push [POWER]
for 1 sec. to turn power ON.
• The internal CPU is reset.
•The transceiver displays its initial VFO frequency when
resetting is complete.
e Correct the set mode settings after resetting, if de-
sired.
Resetting CLEARS all programmed contents in
memory channels and returns programmed values
in set mode to default values.
3
18
BASIC OPERATION
■ When first applying power (CPU resetting)
■ Initial settings
After resetting the transceiver, set controls and
switches as shown in the figure below.
CW : Clockwise
CCW : Counterclockwise
POWER
TRANSMIT
PHONES
ELEC-KEY
MIC
NR
A
/NOTCH
TUNER ANT
HF/VHF TRANSCEIVER
NR NOTCH
AF
MIC GAIN
RF PWR
CW PITCH
F 1
F 2F 3 F 4 F 5
XFC
MP
-
W
GENE
50
0
21
7
24
8 28
9
14
5 10
4
18
6
3.5
2
1. 8
1
7
3
144
ENT
MP
-
R
TX
RX
LOCK
TWIN PBT
M-CH
RIT
CLEAR
∂TX
RIT/∂TX
TS
SPLIT
PBTC
F-INP
A/B
V/M
MW
M-CL
KEY SPEED
P.AMP/ATT NB
VOX/BK-IN
MONITOR
CALL
LOCK/
SPCH
RF/SQL
i7400
MENU
SSB
CW/RTTY
AM/FM
FILTER
[NR]: Max. CCW [NOTCH]: Max. CCW
[AF]: Max. CCW
[TRANSMIT]: OFF
[MIC GAIN]: Max. CCW
[RF PWR]: Max. CCW [CW PITCH]: 12 o’clock
[RF/SQL]: 12 o’clock
[KEY SPEED]: Max. CCW
[POWER] [F-INP] [M-CL]
