Icom IC-A110

■ Panel description
1
1
PANEL DESCRIPTION
V/M SCAN PRI SQL
qw er
tyuio!0
q TUNING [DIAL] [TS](DIAL)
➥ Changes the operating frequency; memory channel in
the Memory mode; set mode contents in the Set mode,
etc.
➥ Push to toggle the dimmer control OFF, Low or High.
➥ Hold down for 1 second to select the Tuning Step [TS];
1 MHz or 10 kHz are selectable. (p. 5)
w FUNCTION DISPLAY (p. 3)
Displays the operating frequency, memory channel name,
etc.
e VOLUME UP [Y] DOWN [Z] KEY
Adjusts the audio output level.
r LOUD SPEAKER
Front mounted loud speaker.
t POWER SWITCH [POWER]
Hold down 0.5 seconds to turn the power ON or OFF.
 •AtPowerON,theInitialSetmode(p.10)ortheCloningmode
(p. 11) can optionally be selected.
