PANEL DESCRIPTION
New2001
i CHANNEL 16/CALL CHANNEL KEY [16•C]
➥ Push to select Channel 16. (p. 5)
➥ Push and hold for 1 sec. to select call channel. (p. 5)
• “CALL” appears when call channel is selected.
➥ Push and hold for 3 sec. to enter the call channel pro-
gramming condition when the call channel is selected.
(p. 8)
➥ While pushing [CH•DUAL], push to enter the channel
comment programming condition. (p. 8)
➥
While turning power ON, push to enter set mode. (p. 39)
o CHANNEL/DUALWATCH/TRI-WATCH KEY [CH•DUAL]
➥ Push to select the regular channel. (pgs. 5, 6)
➥ Push and hold for 1 sec. to start dualwatch or tri-watch.
(p. 12)
➥ Push to stop dualwatch or tri-watch when either is acti-
vated. (p. 12)
!0 DSC MENU KEY [MENU] (p. 13)
Push to toggle the DSC menu ON or OFF.
n Microphone
q PTT SWITCH [PTT]
Push and hold to transmit; release to receive. (p. 7)
w CHANNEL UP/DOWN KEYS [Y]/[Z]
➥ Push to select the operating channels, Set mode set-
tings, DSC menu items, etc. (pgs. 5, 6, 13, 39)
➥ Checks TAG channels, changes scanning direction or
resumes the scan manually during scan. (p. 11)
➥ Push to select the desired digit or character.
(pgs. 8, 13, 14, 17)
e TRANSMIT POWER KEY [HI/LO]
➥ Push to toggle the output power high and low. (p. 7)
• Some channels are set to low power only.
➥
While pushing and holding [HI/LO], turn power ON to
toggle the Microphone Lock function ON and OFF. (p. 9)
