8: I
NSTRUCTIONS
/F
UNCTION
B
LOCKS
R
EFERENCE
8-4 S
MART
AXIS P
RO
/L
ITE
U
SER
'
S
M
ANUAL
FT9Y-B1378
Data Conversion
HTOB Hex to BCD X X
BTOH BCD to Hex X X
HTOA Hex to ASCII X
ATOH ASCII to Hex X
BTOA BCD to ASCII X X
ATOB ASCII to BCD X X
ENCO Encode
DECO Decode
BCNT Bit Count
ALT Alternate Output
CVDT Convert Data Type XXXXX
DTDV Data Divide X
DTCB Data Combine X
SWAP Data Swap X X
Week Programmer
WEEK Weekly Timer
YEAR Yearly Timer
Interface MSG Message
User Communication
TXD2 Transmit 2
TXD3 Transmit 3
RXD2 Receive 2
RXD3 Receive 3
Program Branching
LABEL Label
LJMP Label Jump
LCAL Label Call
LRET Label Return
DJNZ Decrement Jump Non-zero
DI Disable Interrupt
EI Enable Interrupt
IOREF I/O Refresh
HSCRF High-speed Counter Refresh
Coordinate Conversion
XYFS XY Format Set X X
CVXTY Convert X to Y X X
CVYTX Convert Y to X X X
AVRG Average XXXXX
Pulse
PULS1 Pulse Output 1
PULS2 Pulse Output 2
PULS3 Pulse Output 3
PULS4 Pulse Output 4
PWM1 Pulse Width Modulation 1
PWM2 Pulse Width Modulation 2
PWM3 Pulse Width Modulation 3
PWM4 Pulse Width Modulation 4
RAMP1 Ramp Pulse Output 1
RAMP2 Ramp Pulse Output 2
ZRN1 Zero Return 1
ZRN2 Zero Return 2
ARAMP1 Advanced Ramp 1
ARAMP2 Advanced Ramp 2
Dual / Teaching Timer
DTML 1-sec Dual Timer
DTIM 100-ms Dual Timer
DTMH 10-ms Dual Timer
DTMS 1-ms Dual Timer
TTIM Teaching Timer
Group Symbol Name
Valid Data Type
WI D L F
“X” indicates that the instruction is supported.
To Next Page
