IDEC FT1A Series User Manual

S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 A-15
A PPENDIX
Type List
SmartAXIS Pro / Lite
Note: Shared with digital inputs
Type
Power
Voltage
I/O Points
(Input Points/
Output Points)
Input Type Output Type
Type No.
Digital
Input
Analog
Input
(Note)
Relay
Output
(10A)
Relay
Output
(2A)
Transistor
Output
Pro
24V DC
12 points (8/4) 6 2
4
—
—
FT1A-H12RA
24 points (16/8) 12 4 4 FT1A-H24RA
40 points (24/16) 18 6 8
4 (Sink) FT1A-H40RKA
4 (Source) FT1A-H40RSA
48 points (30/18) 22 8 — —
18 (Sink) FT1A-H48KA
18 (Source) FT1A-H48SA
100-240V AC
50/60Hz
12 points (8/4) 8
—
4
—
—
FT1A-H12RC
24 points (16/8) 16 4 FT1A-H24RC
40 points (24/16) 24 12 FT1A-H40RC
48 points (30/18) 30 —
18 (Sink) FT1A-H48KC
18 (Source) FT1A-H48SC
Lite
24V DC
12 points (8/4) 6 2
4
—
—
FT1A-B12RA
24 points (16/8) 12 4 4 FT1A-B24RA
40 points (24/16) 18 6 8
4 (Sink) FT1A-B40RKA
4 (Source) FT1A-B40RSA
48 points (30/18) 22 8 — —
18 (Sink) FT1A-B48KA
18 (Source) FT1A-B48SA
100-240V AC
50/60Hz
12 points (8/4) 8
—
4
—
—
FT1A-B12RC
24 points (16/8) 16 4 FT1A-B24RC
40 points (24/16) 24 12 FT1A-B40RC
48 points (30/18) 30 — —
18 (Sink) FT1A-B48KC
18 (Source) FT1A-B48SC

IDEC FT1A Series Specifications

General

Programming Software	WindLDR
Type	Programmable Logic Controller (PLC)
Display	LCD (varies by model)
Communication Ports	RS232C/RS485 (built-in), USB (programming), Ethernet (optional)
Dimensions	Varies by model
Weight	Varies by model
Model	FT1A Series
