6: HMI F UNCTION
Monitoring the SmartAXIS
Monitoring Device Values
You can check device values on the SmartAXIS. When you switch the SmartAXIS to the device monitor mode from the standard
screen, you can check device values, but you cannot modify them. To modify device values, run Device Monitor on the system
menu. Device values can be monitored regardless of the SmartAXIS operating status (run/stop). This section describes the device
monitor mode when the SmartAXIS is running.
1. If you press the (left) and (right) buttons on the standard screen, the SmartAXIS switches to the device monitor mode
and the device values can be monitored. Continue to press the (left) and (right) buttons to change the device type.
The device type changes in the order below.
I ⇔ Q ⇔ T ⇔ TC ⇔ TP ⇔ C ⇔ CC ⇔ CP ⇔ D (Data Register) ⇔ D (Special Data Register) ⇔ M (Internal Relay) ⇔ M (Special
Internal Relay) ⇔ R
2. Press the (up) and (down) buttons.
The device numbers change.
Modifying Device Values
This section describes how to specify a device and modify that device value.
Modifying a Bit Device Value
This section describes an example of switching on M0012 while the SmartAXIS is running.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Device Monitor with the (up) and (down) buttons and press the (OK) button.
The SmartAXIS switches to the Device Monitor mode.
3. Select device type: M (internal relay) with the (left) and (right) buttons and press and hold the (OK) button.
0 flashes to indicate the focus is on M0000.
I 01234567
I 012345670010
,
0000
,
I 012345670020
,
I 012345670030
,
Running
13:30:40
2012/OCT/10/WED
R 0123456789
0123456789
0123456789
0123456789
R
R
R
000
,
010
,
020
,
030
,
, 
, 



,
, 



, 

,



, 

, 

Shows the on/off state of the inputs (I).
Inverted inputs are on state.
Running
13:30:40
2012/OCT/10/WED
Stop
External Memory
Device Monitor
Program Monitor
M01234567
M 01234567
M01234567
M 012345
0000
,
0010
,
0020
,
0030
,
