6: HMI F UNCTION
6-14 S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378
4. Modify the value with the (up) and (down) buttons and press the (OK) button.
For example, change the value to 700 ms.
• Selectable scroll speeds
The scroll speeds that can be selected are as follows.
500/600/700/800/900/1000 ms
Configuring the Scroll Unit
When the SmartAXIS is stopped, you can configure the scroll unit for messages displayed with the message (MSG) instruction/FB.
This cannot be configured while the SmartAXIS is running.
1. In step 3 of Modifying the Scroll Speed, select Scroll Unit and press the (OK) button.
2. Modify the scroll unit with the (up) and (down) buttons and press the (OK) button.
• Selectable scroll units
The scroll units that can be selected are as follows.
1 character/1 pixel
Configuring the Blinking Speed
When the SmartAXIS is stopped, you can configure the blinking speed for messages displayed with the message (MSG)
instruction/FB. This cannot be configured while the SmartAXIS is running.
1. In step 2 of Configuring the Scroll Speed, select Blink Settings and press the (OK) button.
2. Select Blinking Speed with the (up) and (down) buttons and press the (OK) button.
3. Modify the value with the (up) and (down) buttons and press the (OK) button. For example, change the value to 700 ms.
• Selectable blinking speeds
The blinking speeds that can be selected are as follows.
500/600/700/800/900/1000 ms
Scroll Speed:
700 ms
Scroll Unit:
1-character
Scroll Speed:
500 ms
Scroll Unit:
1-character
Scroll Speed:
500 ms
Scroll Unit:
1-dot
Scroll Settings
Blink Settings
Blinking Speed:
500 ms
Blinking Speed:
700 ms
