6. Select IP Address with the (up) and (down) buttons and press the (OK) button.
7. Specify 6 with the (up) and (down) buttons and press the (OK) button.
8. Press (ESC) button to set the network settings, and then select Yes with the (down) button and press the (OK)
button.
The IP address is set to 192.168.1.6.
• Network settings configuration range
The network settings configuration range is as follows.
Notes:
• When DHCP is enabled, the network settings are automatically obtained and cannot be manually configured.
• You can monitor the current network settings from Status Monitor.
Modifying the Function Settings
Modifying the Scroll Speed
While the SmartAXIS is stopped, you can configure the scroll speed for messages displayed with the message (MSG) instruction/FB.
This cannot be configured while the SmartAXIS is running.
1. In step 4 of Configuring the Slave Number, select Message Settings and press the (OK) button.
2. Select Scroll Settings with the (up) and (down) buttons and press the (OK) button.
3. Select Scroll Speed with the (up) and (down) buttons and press the (OK) button.
DHCP IP Address Subnet Mask Default Gateway
ON/OFF
000.000.000.000 to
255.255.255.255
000.000.000.000 to
255.255.255.255
000.000.000.000 to
255.255.255.255
Network Settings
DHCP: OFF
IP Address:
192.168. 1. 5
IP Address:
192.168. 1. 6
Do you want to
configure network?
No
Yes
Communications
Message Settings
Scroll Settings
Blink Settings
Scroll Speed:
500 ms
Scroll Unit:
1-character
