IDEC FT1A Series User Manual

7: D EVICE A DDRESSES
7-8 S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378
Special Data Registers
Note: Do not change the data of reserved special data registers, otherwise the SmartAXIS may not operate correctly.
Special Data Register Device Addresses
Device Address Description Updated Ladder FBD
See
Page
D8000 Quantity of Inputs When I/O initialized X X 7-11
D8001 Quantity of Outputs When I/O initialized X X 7-11
D8002 SmartAXIS Type Information Power-up X X 7-11
D8003 Memory Cartridge Information Power-up X X 7-11
D8004 — Reserved — — —
D8005 General Error Code When error occurred X X 7-11
D8006 User Program Execution Error Code When error occurred X X 7-11
D8007 — Reserved — — —
D8008
Calendar/Clock
Current Data
(Read only)
Year Every 500 ms X X 7-11
D8009 Month Every 500 ms X X 7-11
D8010 Day Every 500 ms X X 7-11
D8011 Day of Week Every 500 ms X X 7-11
D8012 Hour Every 500 ms X X 7-11
D8013 Minute Every 500 ms X X 7-11
D8014 Second Every 500 ms X X 7-11
D8015
Calendar/Clock
New Data
(Write only)
Year — X X 7-11
D8016 Month — X X 7-11
D8017 Day — X X 7-11
D8018 Day of Week — X X 7-11
D8019 Hour — X X 7-11
D8020 Minute — X X 7-11
D8021 Second — X X 7-11
D8022
Scan Time
Data
Constant Scan Time Preset Value
(1 to 1,000 ms)
—XX7-11
D8023 Scan Time Current Value (ms) Every scan X X 7-11
D8024 Scan Time Maximum Value (ms) At occurrence X X 7-11
D8025 Scan Time Minimum Value (ms) At occurrence X X 7-11
D8026 Communication Mode Information (Port 2 and Port 3) Every scan X X 7-12
D8027 Port 2 Slave Number Every scan X X 7-12
D8028 Port 3 Slave Number Every scan X X 7-12
D8029 System Software Version Power-up X X 7-12
D8030 Communication Adapter Information Power-up X X 7-12
D8031 Optional Cartridge Information Power-up X X 7-12
D8032 Interrupt Input Jump Destination Label No. (I0) — X  7-12
D8033 Interrupt Input Jump Destination Label No. (I2) — X  7-12
D8034 Interrupt Input Jump Destination Label No. (I3) — X  7-12
D8035 Interrupt Input Jump Destination Label No. (I5) — X  7-12
D8036 Timer Interrupt Jump Destination Label No. — X  7-13
D8037 Interrupt Input Jump Destination Label No. (I6) — X  7-12
D8038 Interrupt Input Jump Destination Label No. (I7) — X  7-12
D8039 SD Memory Card Capacity (Megabytes) Every 1 sec X X 7-13
D8040 Analog Input Value (AI0) Every scan X X 7-13
D8041 Analog Input Value (AI1) Every scan X X 7-13
D8042 Analog Input Value (AI2) Every scan X X 7-13
D8043 Analog Input Value (AI3) Every scan X X 7-13
D8044 Analog Input Value (AI4) Every scan X X 7-13
D8045 Analog Input Value (AI5) Every scan X X 7-13
D8046 Analog Input Value (AI6) Every scan X X 7-13
D8047 Analog Input Value (AI7) Every scan X X 7-13
D8048-D8049 — Reserved — — —
