S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 7-11
7: D EVICE A DDRESSES
D8000 Quantity of Inputs
The total of input points provided on the SmartAXIS is stored to D8000.
D8001 Quantity of Outputs
The total of output points provided on the SmartAXIS is stored to D8001.
D8002 SmartAXIS Type Information
Information about the SmartAXIS type is stored to D8002.
D8003 Memory Cartridge Information
When an optional memory cartridge is installed on the SmartAXIS cartridge connector, information about the user program stored
on the memory cartridge is stored to D8003.
D8005 General Error Code
SmartAXIS general error information is stored to D8005. When a general error occurs, the bit corresponding to the error occurred
turns on.
The general error and user program execution error can be cleared by writing “1” to the most significant bit of D8005.
For details on Touch general error codes, see "Troubleshooting" on page 14-1.
D8006 User Program Execution Error Code
SmartAXIS user program execution error information is stored to D8006. When a user program execution error occurs, the error
code corresponding to the error occurred is stored to D8006.
For details on Pro/Lite user program execution error codes, see "User Program Execution Error" on page 14-6.
D8008-D8021 Calendar/Clock Data
D8008 through D8021 are used for reading calendar/clock data from the internal clock and for writing calendar/clock data to the
internal clock.
D8022-D8025 Scan Time Data
D8022 through D8025 are special data registers for checking the scan time and configuring the constant scan time.
For details on the SmartAXIS Pro/Lite scan time, see "Constant Scan Time" on page 5-67.
D8166
Remote I/O
Slave 3
Communication Error Status When error occurred X X 7-15
D8167 Analog Input (AI30) Every scan X X 7-15
D8168 Analog Input (AI31) Every scan X X 7-15
D8169 Analog Input (AI32) Every scan X X 7-15
D8170 Analog Input (AI33) Every scan X X 7-15
D8171 Analog Input (AI34) Every scan X X 7-15
D8172 Analog Input (AI35) Every scan X X 7-15
D8173 Analog Input (AI36) Every scan X X 7-15
D8174 Analog Input (AI37) Every scan X X 7-15
D8175-D8183 — Reserved — — — — —
D8184
Data Register
ROM Backup
Start Address to Read — X X 7-15
D8185 Number of Registers to Read — X X 7-15
D8186-D8199 — Reserved — — — — —
Device Address Description Updated Ladder FBD
See
Page
0:
1:
2:
3:
4:
SmartAXIS Pro/Lite 12-I/O type
SmartAXIS Pro/Lite 24-I/O type
SmartAXIS Pro/Lite 40-I/O type
SmartAXIS Pro/Lite 48-I/O type
SmartAXIS Touch
0:
1:
2:
3:
255:
SmartAXIS Pro/Lite 12-I/O type
SmartAXIS Pro/Lite 24-I/O type
SmartAXIS Pro/Lite 40-I/O type
SmartAXIS Pro/Lite 48-I/O type
The memory cartridge does not store any user program.
