IDEC FT1A Series User Manual

7: D EVICE A DDRESSES
7-10 S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378
D8110
Connection 1 Connected IP Address Every 1 sec
XX
7-14
D8111 XX
D8112 XX
D8113 XX
D8114
Connection 2 Connected IP Address Every 1 sec
XX
7-14
D8115 XX
D8116 XX
D8117 XX
D8118
Connection 3 Connected IP Address Every 1 sec
XX
7-14
D8119 XX
D8120 XX
D8121 XX
D8122-D8129 — Reserved — — —
D8130 Connection 1 Connected Port Number Every 1 sec X X 7-14
D8131 Connection 2 Connected Port Number Every 1 sec X X 7-14
D8132 Connection 3 Connected Port Number Every 1 sec X X 7-14
D8133 Data Register ROM Backup Execution Status
When executing data
register ROM backup
read and write
XX7-15
D8134
High-speed
Counter
(Group 5/I6)
High Word
Current Value / Frequency
Measurement Value (I6)
Every scan
XX
7-13
D8135 Low Word X X
D8136 High Word
Preset Value —
XX
7-13
D8137 Low Word X X
D8138 High Word
Reset Value —
XX
7-13
D8139 Low Word X X
D8140
High-speed
Counter
(Group 6/I7)
High Word
Current Value / Frequency
Measurement Value (I7)
Every scan
XX
7-13
D8141 Low Word X X
D8142 High Word
Preset Value —
XX
7-13
D8143 Low Word X X
D8144 High Word
Reset Value —
XX
7-13
D8145 Low Word X X
D8146
— Reserved — — —
D8147
D8148
Rem
ote I/O
Slave 1
Communication Error Status When error occurred X X 7-15
D8149 Analog Input (AI10) Every scan X X 7-15
D8150 Analog Input (AI11) Every scan X X 7-15
D8151 Analog Input (AI12) Every scan X X 7-15
D8152 Analog Input (AI13) Every scan X X 7-15
D8153 Analog Input (AI14) Every scan X X 7-15
D8154 Analog Input (AI15) Every scan X X 7-15
D8155 Analog Input (AI16) Every scan X X 7-15
D8156 Analog Input (AI17) Every scan X X 7-15
D8157
Remote I/O
Slave 2
Communication Error Status When error occurred X X 7-15
D8158 Analog Input (AI20) Every scan X X 7-15
D8159 Analog Input (AI21) Every scan X X 7-15
D8160 Analog Input (AI22) Every scan X X 7-15
D8161 Analog Input (AI23) Every scan X X 7-15
D8162 Analog Input (AI24) Every scan X X 7-15
D8163 Analog Input (AI25) Every scan X X 7-15
D8164 Analog Input (AI26) Every scan X X 7-15
D8165 Analog Input (AI27) Every scan X X 7-15
