S
MART
AXIS P
RO
/L
ITE
U
SER
'
S
M
ANUAL
FT9Y-B1378 7-9
7: D
EVICE
A
DDRESSES
D8050
High-speed
Counter
(Group 1/I0)
High Word
Current Value / Frequency
Measurement Value (I0)
Every scan
XX
7-13
D8051 Low Word X X
D8052 High Word
Preset Value —
XX
7-13
D8053 Low Word X X
D8054 High Word
Reset Value —
XX
7-13
D8055 Low Word X X
D8056
High-speed
Counter
(Group 2/I2)
High Word
Current Value / Frequency
Measurement Value (I2)
Every scan
XX
7-13
D8057 Low Word X X
D8058 High Word
Preset Value —
XX
7-13
D8059 Low Word X X
D8060 High Word
Reset Value —
XX
7-13
D8061 Low Word X X
D8062
High-speed
Counter
(Group 3/I3)
High Word
Current Value / Frequency
Measurement Value (I3)
Every scan
XX
7-13
D8063 Low Word X X
D8064 High Word
Preset Value —
XX
7-13
D8065 Low Word X X
D8066 High Word
Reset Value —
XX
7-13
D8067 Low Word X X
D8068
High-speed
Counter
(Group 4/I5)
High Word
Current Value / Frequency
Measurement Value (I5)
Every scan
XX
7-13
D8069 Low Word X X
D8070 High Word
Preset Value —
XX
7-13
D8071 Low Word X X
D8072 High Word
Reset Value —
XX
7-13
D8073 Low Word X X
D8074 Backlight ON Time Every scan X X 7-13
D8075-D8076 — Reserved — — î ¸î ¸â€”
D8077 Out of Analog Input Range Status — X X 7-13
D8078
MAC Address (Read only) Every 1 sec
XX
7-13
D8079 XX
D8080 XX
D8081 XX
D8082 XX
D8083 XX
D8084
IP Address (Current Data) Read only Every 1 sec
XX
7-13
D8085 XX
D8086 XX
D8087 XX
D8088
Subnet Mask (Current Data) Read only Every 1 sec
XX
7-13
D8089 XX
D8090 XX
D8091 XX
D8092
Default Gateway (Current Data) Read only Every 1 sec
XX
7-14
D8093 XX
D8094 XX
D8095 XX
D8096-D8103 — Reserved — — î ¸î ¸â€”
D8104 RS232C Control Signal Status (Ports 2 and 3) Every scan X î ¸ 7-14
D8105 RS232C DSR Input Control Signal Option (Ports 2 and 3)
When sending/
receiving data
X î ¸ 7-14
D8106 RS232C DTR Output Control Signal Option (Ports 2 and 3)
When sending/
receiving data
X î ¸ 7-14
D8107-D8109 — Reserved — — î ¸î ¸â€”
Device Address Description Updated Ladder FBD
See
Page
