A-16 S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378
Options
Name Description/specification Type No.
SmartAXIS
Pro/Lite
User’s Manual
Japanese Describes product specifications, installation and wiring
instructions, instructions for basic programming operations
and special functions, device and instruction lists,
communication functions, and troubleshooting procedures
for the SmartAXIS Pro/Lite series.
FT9Y-B1377
English FT9Y-B1378
Chinese (simplified) FT9Y-B1379
German FT9Y-B1380
SmartAXIS
Ladder Programming
Manual
Japanese
Describes basic operations for ladder programming,
instructions for monitoring ladders on the SmartAXIS,
available devices and instruction lists, and details of each
instruction.
FT9Y-B1381
English FT9Y-B1382
Chinese (simplified) FT9Y-B1383
German FT9Y-B1384
SmartAXIS FBD
Programming Manual
Japanese
Describes basic operations for function block programming,
device and function block lists, and function block actions.
FT9Y-B1385
English FT9Y-B1386
Application Software Automation Organizer SW1A-W1C
Communication
Cartridge
Connection Specifications Mini DIN
FT1A-PC1
Standards EIA RS232C
Maximum Baud Rate 115,200bps
Communication Functions
Maintenance communication, User communication, Modbus
RTU master/slave
Isolation between Internal
Circuit and Communication Port
Not isolated
Connection Specifications Mini DIN
FT1A-PC2
Standards EIA RS485
Maximum Baud Rate 115,200bps
Communication Functions
Maintenance communication, User communication, Modbus
RTU master/slave
Isolation between Internal
Circuit and Communication Port
Not isolated
Connection Specifications Terminal block
FT1A-PC3
Standards EIA RS485
Maximum Baud Rate 115,200bps
Communication Functions
Maintenance communication, User communication, Modbus
RTU master/slave
Isolation between Internal
Circuit and Communication Port
Not isolated
End Clips
Used on DIN rail to fasten SmartAXIS modules
(package quantity 10)
BNL6PN10
Direct Mounting Hook Direct mounting hook for 12- and 24-I/O types for maintenance, 5 pcs. FT9Z-PSP1PN05
SD Memory Card Capacity: 2GB HG9Z-XMS2
Memory Cartridge Dedicated user program save memory FT1A-PM1
Maintenance Cable
USB maintenance cable
USB A male to USB mini-B male, 2m
HG9Z-XCM42
USB extension cable (for panel attachment)
USB mini-B female to USB mini-B male, 1m
HG9Z-XCM21
