S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 11-21
11: M ODBUS C OMMUNICATION
Programming WindLDR (Modbus TCP Client)
In order to use the Modbus TCP client, configure the Modbus TCP client in the Function Area Settings dialog box and then
download the user program to the SmartAXIS.
1. From the WindLDR menu bar, select Configuration > Connection Settings.
The Function Area Settings dialog box appears.
2. Select Modbus TCP Client as the communication mode for the connection 1.
The Modbus TCP Client Request Table dialog box appears.
3. Click on the Communication Settings button.
The Communication Settings dialog box appears. Configure the timeout and click OK button to close the Communication
Settings dialog box.

IDEC FT1A Series Specifications

General

Programming Software	WindLDR
Type	Programmable Logic Controller (PLC)
Display	LCD (varies by model)
Communication Ports	RS232C/RS485 (built-in), USB (programming), Ethernet (optional)
Dimensions	Varies by model
Weight	Varies by model
Model	FT1A Series
