S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 11-25
11: M ODBUS C OMMUNICATION
Programming WindLDR (Modbus TCP Server)
In order to use Modbus TCP server, configure the Modbus TCP server in the Function Area Settings dialog box and then download
the user program to the SmartAXIS.
1. From the WindLDR menu bar, select Configuration > Connection Settings.
The Function Area Settings dialog box appears.
2. Select Modbus TCP Server as the communication mode for connection 1.
The Modbus TCP Server dialog box appears.
3. Configure the parameters and click on OK button.
Note: For details about each parameter, see the following page.
4. Download the user program to the SmartAXIS.
Programming for the Modbus TCP server is complete.

IDEC FT1A Series Specifications

General

Programming Software	WindLDR
Type	Programmable Logic Controller (PLC)
Display	LCD (varies by model)
Communication Ports	RS232C/RS485 (built-in), USB (programming), Ethernet (optional)
Dimensions	Varies by model
Weight	Varies by model
Model	FT1A Series
