12: R EMOTE I/O
12-2 S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378
Remote I/O Master
The SmartAXIS can be used as a remote I/O master by configuring the SmartAXIS as a remote I/O master in WindLDR. The
settings can be configured in the Function Area Settings dialog box of WindLDR.
The digital input information from the remote I/O slaves connected with connection 1 through 3 is input to I40 to I75, I80 to I115,
and I120 to I155. The analog input information from the remote I/O slaves is stored to D8149 to D8156, D8158 to D8165, and
D8167 to D8174.
The output information for Q40 to Q61, Q80 to Q101, and Q120 to Q141 on the remote I/O master is output from the remote I/O
slaves connected with connection 1 through 3. For details on data communication between the remote I/O master and the remote
I/O slaves, see "Remote I/O Communication Memory Refresh Image" on page 12-3.
Specifications
Item Description
Connection 1
Digital inputs I40 to I75
Digital outputs Q40 to Q61
Analog inputs D8149 (=AI10) to D8156 (=AI17)
Remote I/O slave 1 communication error status D8148
Remote I/O slave 1 communication error M8005
Remote host
IP address 000.000.000.000 to 255.255.255.255
Port number 0 to 65535
Timeout 100 ms to 25,500 ms (100 ms increments)
Connection 2
Digital inputs I80 to I115
Digital outputs Q80 to Q101
Analog inputs D8158 (=AI20) to D8165 (=AI27)
Remote I/O slave 2 communication error status D8157
Remote I/O slave 2 communication error M8006
Remote host
IP address 000.000.000.000 to 255.255.255.255
Port number 0 to 65535
Timeout 100 ms to 25,500 ms (100 ms increments)
Connection 3
Digital inputs I120 to I155
Digital outputs Q120 to Q141
Analog inputs D8167 (=AI30) to D8174 (=AI37)
Remote I/O slave 3 communication error status D8166
Remote I/O slave 3 communication error M8007
Remote host
IP address 000.000.000.000 to 255.255.255.255
Port number 0 to 65535
Timeout 100 ms to 25,500 ms (100 ms increments)
Refresh period
Communication processing Scan asynchronous
Data update Each scan end
