Set Mag. Encrypt Key: One of security function. When you use SDK, you can encrypt
magnetic stripe encoding data transmitted by USB. You can define and save the
encryption key to SMART-51 using “Set Mag. Encrypt Key”.
② To show how many cards are issued with SMART-51 printer. “Total Issue Count” is the
number of issued cards from factory shipment, “User Issue Count” is the number of
issued cards from replacing head. When you replace a head, please initialize the
number by ticking “Reset User Issue Count”.
③ To show ribbon motor management. SMART-51 recognizes ribbon color automatically
and controls motor by ribbon remaining. “RMP+”, “RMP-“, “RMM+”, “RMM-“ are
necessary variables to control ribbon motor. Please do not change values for them as
it affects card quality.
RMP+: Set the ribbon motor’s max torque value while printing when the balance is
max.
RMP- : Set the ribbon motor’s min torque value while printing when the balance is min.
RMM+: Set the ribbon motor’s max torque value while moving when the balance is
max.
RMM- : Set the ribbon motor’s min torque value while moving when the balance is min.
Ribbon Position: Set the ribbon arrangement position
Ribbon Search Mode: Set the ribbon Search method
Print Wait Time: Set the time from lifting down the print head to starting print
Initial Flipper Angle: Set the angle of flipper when card is out if the ‘Card Out’ is
‘Back’
④ Please refer as below for other values.
Display Type: Set a type of LCD display module.
Display Language: Set the LCD display language.
In the case of Default Character LCD, set to the "English".
In the case of Graphic LCD, set to the "Farsi".
UART Baud Rate: Set the speed of communication of Internal Serial port. It is used for
the KIOSK model.
Security: There are several ways to set a security function for SMART-51.
PC Auth.: You can use a printer with specific PC. It is activated when you click “Set
PC Serial”.
