IDS X64 User Manual

Section: 3
IDS X64 User Manual 700-398-01D Issued August 2010
13
3.1.3
Reading Binary Values
Values within a data program location will be displayed by the zone LEDs in binary coded decimal format
i.e. zone LEDs 1-4 indicate units (ones) and zone LEDs 5-8 indicate tens (tens), and so on.
To read a binary value on the keypad, add up the values represented by each lit LED as shown in Table
2.
Table 2: Values Represented by each Zone LED
Zone LED
Value
Digit
Zone LED
Value
Digit
Zone 1
1
Units
Zone 9
1
Hundreds
Zone 2
2
Zone 10
2
Zone 3
4
Zone 11
4
Zone 4
8
Zone 12
8
Zone 5
1
Tens
Zone 13
1
Thousands
Zone 6
2
Zone 14
2
Zone 7
4
Zone 15
4
Zone 8
8
Zone 16
8
EXAMPLE:
Imagine the following zone LEDs are on: Zone 1, Zone 3 and Zone 5.
Units are represented by the sum of Zone 1 and Zone 3 (i.e. 1 + 4).
Tens of units are represented by the value of Zone 5 (i.e. 1 x ten).
Therefore, the displayed value is (1+4) + (10) = 15.
Values within a time program location are displayed in a similar format as per Table 3.
Table 3: Binary Coded Decimal Four Digit Display
Zone LED
Calculation
Unit
Zone LED
Calculation
Unit
1
(x 1 = 1)
m
9
(x 1 = 1)
s
2
(x 2 = 0)
10
(x 2 = 2)
3
(x 4 = 4)
11
(x 4 = 4)
Mm:Ss
4
(x 8 = 0)
12
(x 8 = 0)
= 54:43
5
(x 1 = 1)
M
13
(x 1 = 1)
S
m = LEDs 4 through 1
6
(x 2 = 0)
14
(x 2 = 0)
M = LEDs 5 through 8
7
(x 4 = 4)
15
(x 4 = 1)
s = LEDs 12 through 9
8
(x 8 = 0)
16
(x 8 = 0)
S = LEDs 16 through 13
Using an LCD keypad means that data and time information can be read directly without a need to
convert.
3.2
Entering Data on an LED Keypad
Data is easily entered on a keypad. Below is a list of keys and their functions.
[*] – This key is used as an enter key, to confirm the data that you have inputted. It is also used to
scroll to the next sub-location.
