Section: 3
IDS X64 User Manual 700-398-01D Issued August 2010
[#] – This key is used to clear data that is incorrect. It can also be used to exit a programming
option.
[F] – This key is used if there is a fire emergency. If programmed to do so, the fire reporting code
will be sent to your monitoring company.
[M] - This key is used if there is a medical emergency. If programmed to do so, the medical
reporting code will be sent to your monitoring company.
[P] - This key is used if there is an emergency situation that requires emergency personnel to
respond. A panic alarm will be transmitted to your monitoring company.
Keys marked 1 through 9, and including 0, are used to input data into the programming options.
[#] WITH any key from [0] to [6] for 1 second
The keypad includes a buzzer that is used for audible signalling and verification of certain keypad
functions. There are 7 possible volume settings: loud being the default setting. To program the keypad
volume, use Table 4:
Table 4: Keypad Buzzer Settings
To change the volume (for this example to the “soft” setting) press the [#] and [1] keys simultaneously
for 1 second (long press). After a 1-second time lapse, the keypad will respond with a beep at the new
volume setting. This is a keypad specific setting, and applies to the keypad that this operation is
performed on.
All zones programmed as Chime or Buzz zones, will sound with a loud buzz regardless of the keypad
volume set above.
[#] [USER CODE]
(Leave via Entry/Exit zone)
1. Ensure that the READY LED is on. If not, check that all protected doors and windows are closed
and that all movement has ceased in areas covered by motion detectors. If necessary, close the
front door.
2. Press the [#] key.
3. Enter a valid [USER CODE]. If an incorrect code is entered, the keypad buzzer will beep three
times. In the event of an error press the [#] key and re-enter the code.
