6. Press the [3] key followed by the [*] key to display which zones were tampered with.
7. Press the [6] key followed by the [*] key to view the event log. (Only on the LCD keypad).
8. Press the [*] key to page through to see zones 17-32. If you press the [*] key again, you will
view zones 33-48. And press the [*] key again to see zones 49-64.
9. After each star press you can repeat steps 4-7 to view the status of the zones.
10. Note that the alarm memory is erased at the beginning of each arm cycle – so it should always
be checked BEFORE re-arming, if necessary.
NOTE:
¾ The READY LED will be on for page 1, zones 1-16.
¾ The ARM LED will be on for page 2, zones 7-32.
¾ The AWAY LED will be on for page 3, zones 33-48.
¾ The POWER LED will be on for page 4, zones 49-64.
This is ONLY viewable on a LCD Keypad; it does NOT work on an LED keypad.
When you view event logs, the LCD display reads as follows:
“HH:MM DD/MM/YYYY”
“eeeeeeeeee p ddd”
Where;
HH:MM = event time MM-DD- YYYY = event date
eeeeeeeeee = event description p = partition event occurred in (if applicable)
ddd = event data (if applicable)
1. The system time and date need to be setup correctly in order for the event log to pull the correct
information. These can be setup in options 40 and 41.
2. When the event log menu is entered, a reference will be taken of the last event recorded. Any
event prior to this reference may be viewed by scrolling back (with the [MED] key) but if the user
decides to scroll forward (with the [PANIC] key) then just events up to and including this
reference point will be viewable.
3. If no event is encountered then the second line will appear as
“No Event - ---”.
4. Pressing [6] followed by [*] after the event log viewing is already active will reset the menu to the
most recent event.
5. Each event description will be followed by two numbered fields if further data is applicable to
describe an event. The first number is the partition number within which the event occurred. The
second number will either be the zone or user number associated with the event type.
Below is an example of how an event will be displayed on the two-line IDS LCD keypad.
“02:00 01/01/2010”
“Violate 2 23”
Translates to: On 1 Jan 2010 at 2AM zone 23 within partition 2 was violated.
NOTE:
The event log will only show the time and date up to the last power up. For a more detailed listing, please
consult your installer.
