Section: 12
IDS X64 User Manual 700-398-01D Issued August 2010
Assign a User Code to Partitions – Option 11 (Advanced)
Hold down the [*] key until the beep,
then enter [MASTER CODE] [*] [1] [1] [*] [USER CODE] [*] [PARTITION No] [*] [#]
1. Enter the User Program Mode as per steps 1 to 4 in section 11.
2. Press the [1] [1] keys followed by the [*] key to select programmable option 11.
3. The READY and ARM LEDs flash simultaneously.
4. Enter the [USER CODE] followed by the [*] key.
5. The READY and AWAY LEDs flash simultaneously, and the ARM LED will be on.
6. The partitions to which the user code is assigned are displayed by the zone LEDs. If zone LED 1
is on, the user code can arm or disarm partition 1. If zone LED 2 is on, the user code can arm or
disarm partition 2. It is possible to program codes to arm/disarm more than one partition.
7. To select which partitions the user code may arm or disarm, toggle zone LEDs by entering the
[PARTITION No] followed by the [*] key.
8. The READY and AWAY LEDs flash simultaneously, and the ARM LED is on.
NOTE:
To allocate a user to all partitions press the [0] key followed by the [*] key, when inputting the
data for the partition number.
9. Repeat step 7 until the user code has been assigned to the correct partition(s).
10. Press the [#] key to exit the current option.
11. Press the
[*] key for the next option, or the [#] key again
to exit user programming.
NOTE:
When a new user is added, they are assigned to partition 1 by default. To change this, or to add them to
other partitions, requires that you program this option. If you do not add a user to a partition, they will not
be able to arm/disarm it.
User Outputs – Option 13 (Advanced)
Hold down the [*] key until the beep,
then enter [MASTER CODE] [*] [1] [3] [*] [USER CODE] [*] [OUTPUT No] [*]
[OUTPUT ACTION] [*] [#]
1. Enter the User Program Mode as per steps 1 to 4 in section 11.
2. Press the [1] [3] keys followed by the [*] key to select programmable option 13.
3. The READY and ARM LEDs flash simultaneously.
4. Enter the [USER CODE] followed by the [*] key.
5. The READY and AWAY LEDs flash simultaneously, and the ARM LED will be on.
6. Enter the [OUTPUT No] followed by the [*] key. (Refer to Table 10).
7. The POWER and READY LEDs flash simultaneously, and the ARM and AWAY LEDs are on.
8. Enter the [OUTPUT ACTION] followed by the [*] key. (Refer to Table 11).
9. The READY and ARM LEDs flash simultaneously.
10. Repeat steps 4 - 9 until all the user outputs you want have been entered.
11. Press the [#] key to exit the current option.
12. Press the [OPTION NUMBER] followed by the [*] key for the next option, or the [#] key again
to exit user programming.
