IDS X64

Section: 12
IDS X64 User Manual 700-398-01D Issued August 2010
29
Table 11: Output Actions Data
Value
Output Action
00
Set Output High (Set)
01
Set Output Low (Reset)
02
Pulse Output High
03
Pulse Output Low
12.10
User Reporting Codes Enable – Option 14 (Advanced)
Hold down the [*] key until the beep,
then enter [MASTER CODE] [*] [1] [4] [*] [USER CODE] [*] [BITMAP] [*] [#]
1. Enter the User Program Mode as per steps 1 to 4 in section 11.
2. Press the [1] [4] keys followed by the [*] key to select programmable option 14.
3. The READY and ARM LEDs flash simultaneously.
4. Enter the [USER CODE] followed by the [*] key.
5. The READY and AWAY LEDs flash simultaneously, and the ARM LED will be on.
6. Enter the [BITMAP] that you want followed by the [*] key.
7. The READY and AWAY LEDs flash simultaneously, and the ARM LED will be on.
8. Repeat step 6 until you have enabled all the reporting codes that you require.
9. Press the [#] key to exit the current option.
10. Press the [OPTION NUMBER] followed by the [*] key for the next option, or the [#] key again
to exit user programming.
Table 12: Enable User Reporting Codes
LED
On / Off
Action
1
ON
Enable close reporting
OFF
Disable close reporting
2
ON
Enable stay close reporting
OFF
Disable stay close reporting
3
ON
Enable open reporting
OFF
Disable open reporting
4
ON
Enable siren cancel reporting
OFF
Disable siren cancel reporting
NOTE:
The options in Table 12 correspond to the options listed in Table 13.
12.11
User Reporting Code Telephone Modules – Option 15 (Advanced)
Hold down the [*] key until the beep,
then enter [MASTER CODE] [*] [1] [5] [*] [USER CODE] [*] [BITMAP] [*] [#]
1. Enter the User Program Mode as per steps 1 to 4 in section 11.
2. Press the [1] [5] keys followed by the [*] key to select programmable option 15.
3. The READY and ARM LEDs flash simultaneously.
4. Enter the [USER CODE] followed by the [*] key.
5. The READY and AWAY LEDs flash simultaneously, and the ARM LED will be on.
6. Enter the [BITMAP] that you want followed by the [*] key.
