ifm Programming Manual ecomatController/60-1 (CR711S) Operating System V2.5.0.n 2017-12-19
Operation Data transmission for series production
>
9.5.2 Data transmission with TFTP
23580
With the aid of the program TFTP, files can be transferred.
Transfer file from device to PC:
tftp -i IP-A dresse GET s ource target
IP address = address of the source device, e.g. 192.168.82.247
Source = source file on the device
Target = target file on the PC
Transfer file from PC to device:
tftp -i IP-Adresse PUT source target
IP address = address of the source device, e.g. 192.168.82.247
Source = source file on the PC
Target = target file on the device
Example:
tftp -i 192.168.82.247 PUT [Windows-Pfad]\ifmOS.ifm \os\ifmOS.ifm
>
9.5.3 Files for series production
23578
The following files must be transferred:
Data name / path
Description
apps
Folder
 standard.app
Application non-safe
 safe.app
Application safe
os
Folder
 ifmOS.ifm
ifmOS
cfg
Folder
 comconf.cfg
Communication configuration
 memconf.ifm
Memory configuration
The following file must be transferred according to the kind of application (retain data and free user
data):
Data name / path
Description
retain
Folder
 standard.ret
Application retain non-safe
 standard.mb
Application memory bytes non-safe
 safe.ret
Application retain safe
 safe.mb
Application memory bytes safe
data
Folder
 *.*
Memory space for user-defined data
