ifm Programming Manual ecomatController/60-1 (CR711S) Operating System V2.5.0.n 2017-12-19
ifm function libraries Library ifmOutHBridge
>
10.7.2 MODE_BRAKE (ENUM)
23480
Name
Description
Possible values
MODE_BRAKE
Braking mode that is applied when
changing the direction (xDirection)
or when stopping (uiValue = 0).
UNCHANGED
Setting remains unchanged
BRAKE_OFF
No braking. The voltage direction
is changed immediately.
BRAKE_EMCY
Emergency brakes:
 In case of change of direction:
Braking only during
tBrakeTime.
 When stopping: Braking
during and after the
tBrakeTime is elapsed.
BRAKE_EMCY_BTIME
Emergency brakes, but only
during tBrakeTime.
BRAKE_DYNAMIC
Like BRAKE_EMCY mode, but
dynamic braking with the
uiBrakeValue.
BRAKE_DYNAMIC_BTIME
Like BRAKE_EMCY_BTIME
mode, but dynamic braking with
the
uiBrakeValue.
>
