ifm Programming Manual ecomatController/60-1 (CR711S) Operating System V2.5.0.n 2017-12-19
System configuration Configure interfaces
>
7.3.4 Interface configuration file comconf.cfg
22929
The file directory /com of the device contains the file comconf.cfg.
To change the configuration data of the following interfaces, this file must be written into the device
with the corresponding changes:
• Serial interface
• Ethernet interface
• CAN interfaces
Factory setting of the content:
[ETHERNET]
Number=1
[ETHERNET0]
IpV4Address=192.168.82.247
IpV4SubnetMask=255.255.255.0
IpV4Gateway=192.168.82.21
UDPPort=12345
[CAN]
Number=4
[CAN0]
Baud rate=250000
NodeId=127
[CAN1]
Baud rate=250000
NodeId=126
[CAN2]
Baud rate=250000
NodeId=125
[CAN3]
Baud rate=250000
NodeId=124
[COM]
Number=1
[COM0]
Baud rate=115200
Bits=8
Parity=0
Stop=1
► To start the (deactivated) device with these default settings:
(the file comconf.cfg is not taken into consideration)
TRUE on connection RESET-COM (Pin 72) simultaneous wtih POWER-ON
After the start-up: FALSE on RESET-COM
► To start the (deactivated) device with the content of the (new) file comconf.cfg:
FALSE on connection RESET-COM (Pin 72) simultaneously with POWER-ON
