3D sensor
UK
6.3 Install sensor
Observe the following instructions when installing the sensor:
► Mount the sensor using 2x M5 screws or mounting set.
> The bore dimensions for the M5 screws are indicated in the data sheet.
> The mounting set is available as accessories (→ 6.4).
► Use strain reliefs for all cables connected to the device.
Observe the following instructions when installing an O3D300 and O3D310:
► Mount the sensor so that the focal setter can be accessed with a screw driver.
> The position of the focus adjustment screw is indicated in the scale drawing (→ 12).
If the device is permanently used in wet areas, the nut of the M12 Industrial Ethernet cable (e.g.
E11898) may corrode. Use a cable with a high-grade stainless steel nut for permanent use in wet
areas.
6.4 Mounting accessories
Depending on the location and type of installation, you can use the following mounting accessories:
Article number Description
E3D301 Smart Camera mounting set
E3D302 Smart Camera cooling element
E3D303 Smart Camera heat conductor
E3D304 2x Smart Camera cooling element
You can find more information about the accessories at:
www.ifm.com
