HTM-1505R/HTM-1505CS
@ R.BACKGROUND switch
Used to ac(just the white balance (reel component) oflow light po1tion.
For how to adjust, refer to 4-10 (3).
@ G.BACKGROUND switch
Used to adjust tl1e white balance (green component) oflow light po1tion.
For how to ac!just, refer to 4-10 (3 ).
@ 8.BACKGROUND switch
Used to ac!just the white balance (blue component) oflow light portion.
For how to adjust, reter to 4-10 (3).
@) G.GAIN switch
Used to ac{just the white balance (green component) of highlight po1tion.
For how to ac[just, refer to 4-10 (3).
@) B.GAIN switch
Used to ac(ju,t the white balance (green component) of highlight portion.
For how to adjust, refer to 4-IO ( 3 ).
@ HUEswitch
Used to adjust IIUE data.
Circuit operates only when analog/digital (D2) NTSC composite
signal input equipped with NTSC decoder module DE-801 is
selected.
For how to ac{just, refer to 4-10 (4 ).
@ CHROMA switch
· Us1::cl to ac[just CHROMA data.
• For how to ac[iusl, refer to 4-IO ( 4 ).
@ BRIGHT switch
• Used to ac(iust BRIGHTNESS data.
It does not operate at the time of DELAY.
For how to adjust, refor to 4-10 (I).
® CONT switch
· Used to adjust CONTRAST data.
· For how to adjust, refor to 4-IO (2).
@ STORE FILE switch
22
Used to copy color-temperature data currently displayed to FILE I to
FILE3.
When the switch is pressed, FILE I to FILE 3 blink., and when the
FILE switch of storage location is pressed, the LED lights up to copy
the data
Preset data to be stored are the following 9 kinds of data enclosed
with the white frame on the panel:
HUE
CHROMA
R.BKG G.BKG
BRIGHT
B.BKG
CONT
G.GAIN
B.GAIN
@ FILE 1 switch
Tum it on when outputting data that is stored in FILE I, or when
memorizing data in it.
®J FILE 2 switch
Tum it on when outputting data that is stored in FILE 2, or when
memorizing data in it.
@ FILE 3 switch
Tum it on when outputting data that is stored in FILE 3, or when
memorizing data in it.
@) MENU switch
Used to call various mem_1s.
@ ENTswitch
Used to finalize the menu manipulation.
@ ESCswitch
· Used.to return from the menu manipulation.
@ U.DISPLAY switch
• It is not available in the present version.
@ ASP-BO Connector
Connector provided to connect auto set-up probeASP-80 (option].
@ Rotary Encoder
Used to change preset data in the drawer panel and select a mode of
menu, etc.
To Next Page
