illumina MiniSeq User Manual

2 If present, remove the used reagent cartridge.
NOTE
To facilitate safe disposal of unused reagent containing formamide, the reservoir in position #9 is
removable. See Remove Used Reservoir from Position #9 on page 30.
3 Slide the reagent cartridge into the reagent compartment until the cartridge stops.
Figure 14 Load Reagent Cartridge
Empty the Spent Reagents Bottle
1 Remove the spent reagents bottle from the compartment.
Figure 15 Remove the Spent Reagents Bottle
2 To prevent spills when carrying the spent reagents bottle, seal the bottle opening with the threaded cap.
Document # 1000000002695 v02 Material # 20014309
For Research Use Only. Not for use in diagnostic procedures.
22
MiniSeq System Guide

illumina MiniSeq Specifications

General

Instrument Type	Benchtop Sequencer
Sequencing Technology	Sequencing by Synthesis (SBS)
Read Length	Up to 2 x 150 bp
Output	Up to 7.5 Gb
Run Time	4 - 24 hours
Data Quality	≥ 80% bases ≥ Q30
Maximum Reads	25 million
Sample Capacity	1
Applications	Targeted Gene Sequencing, Small Genome Sequencing, Amplicon Sequencing, Gene Expression Profiling
Power Requirements	100-240 V, 50-60 Hz
Operating Temperature	19°C to 25°C
Operating Humidity	Non-condensing, 20% to 80% RH
