Load the Buffer Cartridge
1 Remove the used buffer cartridge from the upper compartment.
Some force is required to lift and then pull out the buffer cartridge.
2 Slide a new buffer cartridge into the buffer compartment until it stops.
An audible click indicates that the cartridge is in position, the buffer cartridge ID appears on the
screen, and the sensor is checked.
Figure 16 Load the Buffer Cartridge
3 Close the buffer compartment door, and select Next.
Load the Reagent Cartridge
1 Open the reagent compartment door using the latch under the lower-right corner of the door.
2 Remove the used reagent cartridge from the reagent compartment. Dispose of unused contents in
accordance with applicable standards.
WARNING
This set of reagents contains potentially hazardous chemicals. Personal injury can occur
through inhalation, ingestion, skin contact, and eye contact. Wear protective equipment,
including eye protection, gloves, and laboratory coat appropriate for risk of exposure.
Handle used reagents as chemical waste and discard in accordance with applicable
regional, national, and local laws and regulations. For additional environmental, health, and
safety information, see the SDS at support.illumina.com/sds.html.
NOTE
To facilitate safe disposal of unused reagent, the reservoir in position 6 is removable. For more
information, see
Remove Used Reservoir from Position #6
on page 22.
3 Slide the reagent cartridge into the reagent compartment until the cartridge stops, and then close the
reagent compartment door.
Document # 1000000041922 v01
For Research Use Only. Not for use in diagnostic procedures.
21
NextSeq 550Dx Research Mode Instrument Reference Guide
