Figure 23 Load the BeadChip Adapter
2 Select Load.
The door closes automatically, the BeadChip ID appears on the screen, and the sensors are
checked. A short delay is normal. If the BeadChip barcode cannot be read, a dialog box appears that
allows you to enter the barcode manually. See
Software Cannot Read the BeadChip Barcode
on
page 48.
3 Select Next.
Scan Setup
1 On the Scan Setup screen, confirm the following information:
u Barcode—The software reads the BeadChip barcode when the BeadChip is loaded. If the
barcode was entered manually, the Edit button appears for further changes.
u Type—The BeadChip type field is autopopulated based on the BeadChip barcode.
u DMAP Location—The DMAP folder location is specified on the BeadChip Scan Configuration
screen. To change the location for the current scan only, select Browse and navigate to the
correct location.
u Output Location—The output location is specified on the BeadChip Scan Configuration screen.
To change the location for the current scan only, select Browse and navigate to the preferred
location.
2 Select Next.
Review Pre-Run Check
The software performs an automated pre-run check of the system. During the check, the following
indicators appear on the screen:
u Gray checkmark —The check has not been performed yet.
u Progress icon—The check is in progress.
u Green checkmark—The check passed.
u Red X —The check did not pass. For any items that do not pass, an action is required before you
can proceed. See
Resolve Automatic Check Errors
on page 44.
To stop an automated check in progress, select the Cancel button. To restart the check, select the
Retry button. The check resumes at the first incomplete or failed check.
To view the results of each individual check within a category, select the category tab.
Document # 1000000041922 v01
For Research Use Only. Not for use in diagnostic procedures.
31
NextSeq 550Dx Research Mode Instrument Reference Guide
