Hydronic Functions
Overview of Hydronic Functions
TA-SCOPE enables various alternatives for exploring and diagnosing hydronic systems. On screen diagrams will
guide you through the physical set up of the measurement equipment as required for the hydronic function you
would like to perform.
The hydronic functions then enable the system data to be used effortlessly in many flexible and useful ways.
The main hydronic functions of TA-SCOPE, where system data can be collected and applied, are as follows:
Quick Measure – Straightforward function to measure flow, differential pressure (∆p), temperature and
power. To be used when only one or a few valves are of interest. The function does not require any
predefinition of network or module.
Hydronic Networks – Complex networks created in HySelect are easily downloaded to TA-SCOPE.
Use a network for measuring and balancing at any time; during commission, for control and inspection.
All hydronic functions can be applied to a selected valve from a Hydronic Network.
Balancing – The powerful TA-Wireless and TA-Diagnostic methods for balancing hydronic systems.
TA-Wireless makes use of two Dp Sensors with wireless technology to easily perform balancing of a
hydronic module. With TA-Diagnostic, you measure all valves in a module. The method calculates a Dp
diagnostic for the module and correct valve openings to attain design flows.
Troubleshooting – Software wizards take you step-by-step through the process of locating and
diagnosing problems and errors in hydronic systems, e.g., Dp (∆p) analysis.
Data Logging – Measurement during a predetermined period of time to analyse any fluctuations in flow,
differential pressure (∆p), temperature and power. The logged data is stored and listed or displayed as a
graph, both in TA-SCOPE and HySelect.
