IMI Hydronic TA-SCOPE - Delete Network

TA-SCOPE
24
Hydronic Networks
Delete Network
It is possible to delete the entire network from the Hydronic Network main menu.
1 Navigate
to the network to be deleted.
2 Press function key Options.
3 Select Delete and press enter.
4 Press function key Yes and the network disappears from the list.
5 To delete individual circuits in a network, navigate
to each circuit and delete one by one.
6 Open the network and navigate
to the circuit.
7 Press function key Options and select Delete.
Create a Hydronic Network
Is also possible to create a network directly in the TA-SCOPE if no Hydronic Network has been downloaded from
HySelect.
1 Press function key New from the Hydronic Network main menu.
2 Enter network name and optional description. Dot key works as caps lock. For a dot keep the key pressed until a
dot appears. Numerical keys works the same, a prolonged press enters a digit.
3 If needed, edit the fluid settings. Navigate
to and press enter, more Fluid details on page 34.
4 Press function key Create and the new network appears in the list displayed at Hydronic Networks main menu.
5 Select
the new network and press enter.
6 Add content to the network. Press function key Options and select
Add circuit, press enter.
7 Tick the box for Circuit with terminal units by pressing enter if there is a terminal.
8 TA-SCOPE enables several balancing options for the circuits. Navigate
to the Balancing With drop down
list and press enter. Scroll the list and press enter to select. Contact your local IMI Hydronic Engineering
sales office for more details on hydronic systems with Dp controller.
9 Press the function key Continue.
10 Define Valve
for the circuit. Valve type and size from previous input is default, cycle the sizes with or
press enter to open Define valve menu.
11 For terminal circuits Design flow
can be entered (optional).
12 Enter number of circuits to add.
13 Press function key Add.
