View Saved Measurements
1 Select View Saved Measurements from the Quick Measurements main menu, press enter.
2 Measurements are displayed in a list showing reference i.e., the entered name, type of measurement and date/time.
3 Press function key View to open up details on the measurement in focus.
4 Delete measurements one by one using the function key Delete.
5 Delete all saved measurements from the function key Options and navigate
to Delete all quick
measurements, press enter.
Flow Adjustment – Computer Method
TA-SCOPE enables a method for correcting the flow to attain desired flow for terminals with a given design flow.
TA-SCOPE will lead you through the process.
1 Whilst measuring on a valve press
or function key Option and navigate to Flow Adjustment (Computer
Method), press enter.
2 Shut the valve and press function key Done.
3 Measurement will continue and display differential pressure (∆p) for the closed valve.
4 TA-SCOPE automatically calculates a new handwheel position in order to attain design flow.
5 Adjust handwheel accordingly and press function key Recalculate.
6 If needed, perform further calculations and handwheel adjustments to reach the desired flow.
7 Finish the adjustment by pressing function key Quit.
Kv-mode for non-IMI TA valves
TA-SCOPE is supplied containing an up-to-date database of IMI TA valves. However measurements on non-IMI
TA valves are also possible. Instead of selecting a IMI TA valve the Kv-value can be used.
1 Press function key Options, navigate
to Switch to Kv-mode, press enter.
2
icon is shown instead of and the valve properties can not be adjusted.
3 Once in Kv-mode, quick measurement operations are continued in Kv-mode until you switch back to IMI TA valve
mode.
Change Units
Default units in TA-SCOPE are automatically preset according to your market. However all units can be changed
depending on your personal preferences.
1 Press function key Units to change any of the units.
2 Navigate up and down in the list.
3 Cycle the alternatives
or press enter to display the alternatives and enter to select.
4 The function key Reset will bring back the default unit for the one in focus.
5 Press function key Reset all to set the default units for all parameters.
6 Return to measuring menu by pressing function key Quit or
from the keypad.
Quick Measure
Tips! Easily change units directly from the measuring menu – navigate to the measurement
row e.g., Flow and press repeatedly to cycle available units.
!
