TA-SCOPE
45
Measurement range
Total pressure
– TA-SCOPE....................................................... max 1 600 kPa
– TA-SCOPE HP ................................................. max 2 500 kPa
Differential pressure
– TA-SCOPE.............................................................. 0-500 kPa
– TA-SCOPE HP ..................................................... 0-1 000 kPa
Recommended pressure range during flow measurements
– TA-SCOPE.............................................................. 1-500 kPa
– TA-SCOPE HP ..................................................... 3-1 000 kPa
Temperature liquid medium measurement ............ -20 – +120°C
Measurement deviation
Differential pressure
– TA-SCOPE....................................... 0.1 kPa or 1% of reading,
whichever is the highest
– TA-SCOPE HP ................................. 0.2 kPa or 1% of reading,
whichever is the highest
Flow ........................ as for differential pressure + valve deviation
Temperature ....................................................................<0.2°C
Battery capacity, operating and charge times
Handheld unit battery, capacity ................................. 4 400 mAh
– operating time (with backlight on) ....................................>25 h
– charge time to full capacity ............................................. 6-7 h
Dp sensor unit battery, capacity ................................ 1 400 mAh
– operating time (continuous measurements) .....................>25 h
– charge time to full capacity ..............................................2.5 h
Logging time (in sleep mode) ..................................... >100 days
Relay battery, capacity .............................................. 4 400 mAh
– operating time .................................................................>25 h
– charge time to full capacity ............................................. 6-7 h
Ambient temperature
During operation ............................................................. 0-40°C
During charging .............................................................. 0-40°C
During storage*) ...................................................... -20 – +60°C
*) Do not leave water in the sensor when there is a risk of freezing.
Humidity
Ambient humidity ...................................................max. 90%RH
Sealing
Handheld unit (in wireless mode).........................................IP 64
Dp sensor unit DpS-Visio (in wireless mode) .......................IP 64
Safety pressure and temperature probe ..............................IP 65
Digital temperature sensor ..................................................IP 65
Relay ..................................................................................IP 44
IP4X = ingress of solid foreign objects >1mm diameter
IP6X = dust tight
IPX4 = protected against splashing water
IPX5 = protected against water jets
Dimensions/Weight
Handheld unit .......................................... 205x96x29 mm, 365g
Dp sensor unit DpS-Visio ....................... 120x120x56 mm, 630g
Display
Handheld
– Size .................................................................................. 3.5”
– Number of dots .........................................................320x240
– LCD type ...........................................................................TFT
– Colour ................................................................ 262K (24BIT)
– Back light ............................................................. LED WHITE
DpS-Visio
– Size .................................................................................. 1.5”
– Number of dots .........................................................128x128
– Type ............................................................................... OLED
– Colour ............................................................................ 265K
Data storage
Storage of measured data ................................... > 2 000 valves
Logging of data (3 channels) .......... 3 x 40 000 measuring values
Wireless
Wireless (between handheld and Dp sensor, 2.4 GHz)
Range in open space .............................................approx. 70 m
Range indoors ..................................................approx. 20-30 m
Wireless (between two relays, 868 MHz – EC version,
915 MHz – FCC version)
Range in open space ...........................................approx. 500 m
Range indoors ................................................ approx. 5-6 floors
Multi-charger
Input voltage .............................................................. 100-240 V
Input frequency ............................................................ 50-60 Hz
Output voltage ................................................................ 5.2 V =
Output current ............................................................. 6000 mA
Technical specifiactions valid at an altitude of max. 2000 m.
