5 | Installation INFICON
28 / 108 XL3000flex-Operating-instructions-jina83en1-07-(2105)
5 Installation
The structure of the device, see “Device setup [}14]“.
5.1 Setup
CAUTION
Risk of injury from lifting the heavy device
The device weighs approx. 37 kg and can slip out of your hands.
► Lift and transport the device only with persons who are physically able to do so.
► Lift and transport the device at least in pairs.
► To lift, grasp the handle grips on the sides of the device.
► To avoid crushing the hands, the feet of the device must not point upwards when it
is lifted or transported.
► The device must not be lifted and transported with just one handle.
CAUTION
Risk of injury due to improper installation
If the device is not placed on a flat, non-slip surface, it may fall and cause personal
injury or property damage.
► Place the device on a level, slip-proof work area.
NOTICE
Material damage from overheated device
The device heats up during operation and can overheat without sufficient ventilation.
► Please note the technical data.
► Ensure sufficient ventilation, especially on the ventilation slots on the rear and
bottom: There should be free space in the front, to the rear and sides of the unit of
at least 20 cm.
► Device should be placed on a flat surface to ensure proper air intake from the
bottom of the device.
► Keep heat sources away from the device.
