5 | Installation INFICON
30 / 108 XL3000flex-Operating-instructions-jina83en1-07-(2105)
5.2 Connecting the sniffer line
Connect the sniffer line before you start up the device.
1 Connection for sniffer line
1
Align the red marking on the sniffer line plug with the red marking on the socket
of the device.
2
Push the sniffer line plug into the socket on the device until it locks into place.
The plug may no longer be easy to move.
5.3 Mounting the I/O module or bus module
(optional)
Both modules are interfaces for controlling the leak detector XL3000flex.
