Installation and programming manual
General information 11
2.11.2 Graphic conventions
Following are the graphic conventions used in the text. For a description of the graphic conventions relating
to the interface, refer to paragraph 5.1 - SmartLight panel frontplate.
Note: The detached notes contain important information about the text.
Attention: The attention prompts indicate that total or partial disregard of the procedure could damage
the connected devices.
Danger: The danger warnings indicate that total or partial disregard of the procedure could injure the
operator or persons in the vicinity.
2.12 Menu paths
Example:
From panel: <key>, Configuration, Loop, Ok, Loop Parameters
Via software application: Control panel, Loop
Access to specific functions can be achieved by using the panel keys or PC video objects and the respective
path.
Note: This manual describes the recommended programming flow. This manual describes the loop
configuration procedure from the panel, as indicated in the example.
Attention: For most part this manual describes programming from the control panel.
Conventions Example Description
Text in Italics Refer to paragraph 4.1 Text in italics: indicates the title of a chapter, section,
paragraph, table or figure in this manual or other published
reference.
<text> #<CustomerCode> Variable data.
[lowercase letter]
or [number]
[A] or [1] Representation of a part of the system or video object.
BUTTON Esc, RESET Computer or control panel keys.
