Installation and programming manual
Technical description 17
Note: INIM s.r.l. reserves the right to change, replace, in part or entirely, the components not strictly relating
to the user and therefore, which do not involve the installation process described in Chapter 6 -
Installation instructions.
4.2 Technical specifications
4.3 PCB current draw
[K] Connector for the earth wire of the power supply module
[L] Power-supply module connector
[M] Battery connector
[N] Thermal probe connector for batteries - accessory item
[O] Earth-fault-bypass jumper - if this jumper is removed faults will be bypassed
[P] Jumper for programming from panel (keypad and LCD) J8
[Q] Jumper for programming from PC J9
[R] Extinguishant module connector
[S] Buzzer
AC power 230 Vac (-15% + 10%) 50/60 Hz
Maximum current draw 230V 0.5 A
Maximum current draw on terminal +AUX 0.8 A
Current ripple on AUX and AUX-R outputs 1% MAX
Maximum battery-charge current 400mA
Battery specifications 2 x 12 V/7 Ah YUASA NP-12 FR or similar with case
flame class UL94-V2 or higher
Maximum battery internal resistance (R
i max
)23 Ohm
Output current 19V - 27.6V
Fuse (F2) - Switching power supply F 6.3 A 250V
Fuse (F1) - Switching power supply (not resettable) T 3.15 A 250V
Maximum output current ripple 1%
Operating temperature -5°C to 40°C
Dimensions 325 x 325 x 80 mm
Weight 2.8Kg
Module Standby current draw Maximum current draw
SmartLight motherboard 70 mA 120 mA
SmartLetLoose/ONE fire extinguishant board 10 mA 70 mA
SmartLetUSee/LCD-Lite repeater 40 mA 80 mA
