Installation and programming manual
General information 9
Chapter 2
General information
2.1 Documentation supplied
• Installation and programming manual (this manual)
• User's Manual
The Installation manual is inside the device package. For further copies of the Installation manual contact
the offices at INIM Electronics s.r.l. and quote the order number printed in Appendix D - Order Codes.
2.2 Manual details
• Title: SmartLight Installation and Programming Manual
• Version: 3.0
• Month and year: 2012
• Code: DCMIINE0SLIGHT
• Addressees: installers, technical assistance
2.3 Firmware information
• SmartLight firmware version: 2.0.x
• Extinguishant module firmware version: 1.0.x
2.4 Operator qualifications - access levels
The SmartLight is EN-54 compliant. There are four access levels:
Level 1: All building occupants.
All building occupants can view the system status (active events) and events log; silence the
panel beeper and, under pre-alarm conditions, override pre-alarm status and activate an
instant alarm.
Level 2: Authorized operators — person/s responsible for the safety of the building and its occupants.
Authorized operators (keyswitch and PIN users) can silence the outputs; reset the panel;
activate the 'Investigation' delay; disable zones, points and outputs; change the operating
mode (Day/Night) and activate the 'Evacuation' alarm.
Level 3: Authorized technicians appointed by the Installer company.
Such technicians possess the tools required for the removal of the control panel frontplate. And,
are allowed to insert the jumper which enables the control panel programming phase (via
control panel or PC), in order to access the programming and maintenance functions. The
events cannot be accessed during the programming phase.
Level 4: Authorized technicians, appointed by the Manufacturer (INIM Electronics s.r.l.).
The manufacturer company technicians can, by means of special tools, repair or replace the
control panel components.
Note: This manual is for Authorized installer company technicians (Level 3). However, it also provides some
installation information related to level 1 and level 2.
2.5 Intellectual property rights
The information contained in this document is private property. All rights reserved.
No part of this document may be copied or reproduced unless expressly authorized in writing by INIM
Electronics, in particular the parts regarding the device specified inparagraph 2.13 - Device identifier INIM
Electronics s.r.l. shall not be responsible for damage arising from improper application or use.
