Installation and programming manual
Enea series devices 61
Appendix A
Enea series devices
All devices in INIM ELECTRONIC's new Enea series of addressable-
analogue detection devices are LPCB certified and carry the CE mark
according to CPD.
Each device is equipped with a short-circuit isolator which, in the event of short-circuit between two
control-panel (loop) connection wires, is capable of interrupting the negative wire and isolating the wire
section concerned. The loop supports up to 240 devices. Each device is identified by a factory-assigned
serial number which allows automatic addressing.
The Enea series of INIM Electronics provides three analogue detector model:
• Optical chamber with sealed upper-part and 500 micron hole-diameter mesh insect screen
• Tricolour LED - Red for alarm, Green flash for standby and for identification from the control panel;
Yellow for fault status
• Supervised remote output configurable from the control panel
• Automatic recognition of remote signaller connection
• Drift compensation for sensor drift caused by dust in the chamber
• Sensitivity selection for smoke and heat thresholds
• Operating mode selection (for ED300 version) - Only smoke; Only heat
• AND mode, OR mode, PLUS mode
• Complete diagnostics - provides contamination level and real-time values
• Memory of the smoke and temperature levels measured in the five-minute period prior to the last alarm
detected
• Bypass plate on base guatantees continuity in the event of removal of the detector from the line
For further details regarding the precise features and technical specification of each device, refer to the
respective instructions booklet.
Type Model Description
Detectors ED100 Optic smoke detector
ED200 Heat detector
ED300 Smoke and heat detector
Bases EB0010 Mounting base
EB0020 Relay base
ESB010 Sounder base (to be installed under EB0010 mounting base)
ESB020 Sounder base and beacon (to be installed under EB0010
mounting base)
Modules EM312SR Input and Output module
EM110 Input module
EM311 Micromodule
EM344S 4 input + 4 output conventional zone interface
Manual
Callpoints
EC0010 Manual callpoint
EC0010E Manual callpoint for outdoor installation (IP67)
Alarm repeater FI100 Remote addressable alarm repeater
