6.9 The AUX output
The AUX terminals provide the 24 V power supply to the peripheral devices. The output is protected by a
resettable fuse @ 0.9 A.
In the event of short-circuit, the panel will signal a fault.
Terminal
Device to be
connected
Input Type Note Wiring Diagram
MAN-EXT Extinction system
Start button
Supervised. Up to 20 devices can be connected to
this input.
Figure 21 -
Extinguishant
module/A
47K = Standby
15K = Active
STOP-EXT STOP
extinguishant-
system button
Supervised. The STOP extinguishant-system button
should always be located near to the
protected area. This will allow any
persons present during the release of
extinguishant gas to stop the process
and evacuate the area unharmed. Up
to 20 devices can be connected to this
input.
PRESS Gas extinguishant
pressure switch.
Supervised. The pressure switch has two functions:
- Under normal operating conditions, it
monitors the pressure of the Gas
extinguishant. If the pressure drops
spontaneously below the pre-set value,
it will generate a fault signal.
- After an 'Extinction' command, it
confirms that the command has been
executed.
Terminal
Device/s to
connect
Output Type Note Wiring Diagram
VALVE Electrovalve for
gas release.
Supervised Figure 21 -
Extinguishant
module/B
PRE-EXT Audible and Visual
signaling devices
Supervised The signaling devices activate as soon as
the detectors sense fire conditions that
require gas extinguishant intervention.
This will allow building occupants to
evacuate the building before the gas
extinguishant is released. The delay
between the activation of alarm signaling
devices and the release of the gas
extinguishant is customizable.
Figure 21 -
Extinguishant
module/C
47K Balancing
RELEASED “Extinguishant
Gas release”
signaling devices
Supervised There are two activation modes:
- activation on confirmation of
Extinguishant Gas release;
- simultaneous activation with the
electrovalve output. This mode requires
gas detectors in the protected
environment.
R Remote LED that
signals the
deployment of the
STOP
extinguishant-
system button.
Open Collector
(non-
supervised)
Activates (closes to GND) in the event of
activation of the STOP EXT input (max
100 mA).
Figure 21 -
Extinguishant
module/D
