Installation and programming manual
Powering up and configuring the system 39
The panel will take several seconds to stabilize, startup will be indicated by an intermittent audible
signal and the “
Resetting”.
Figure 27 - Reset signaling
Full panel reset will be indicated by:
- The On status of the green LED (paragraph 5.1.2 - [S]) indicates that the panel is operating.
- The CPU LED (paragraph 5.1.2 - [P]) will blink to indicate that the board is initializing.
- If you do not carry out the successive step (connection to the mains power source) within 2 minutes,
the FAULT LED (paragraph 5.1.2 - [O]) will go On and the “
Mains Fault” message will appear on the
display.
4. Power up the panel from the mains.
In the event of restoral of a Mains fault; the FAULT LED will blink to indicate that the event has been
saved to the memory.
5. If the fault persists, check all wiring sections thoroughly. See Chapter 17 - Diagnostics and fault
solutions.
6. Once all faults have been cleared, turn the key in the keyswitch (Access Level 2) and press the RESET
button (paragraph 5.1.1 - [D]).
After Reset operations, all the LEDs should go OFF, with the exception of the green ON LED (paragraph
5.1.2 - [S]).
The display will show “
Panel working” message.
7. Press any key to access the main menu. Using the cursor key T select the second option on the “
Test
LEDs
” menu. Press and hold the Ok key and check that all the LEDs go On.
Control panel
In service
14/05/11 18:23
