4 Table of contents
Installation and programming manual
7.1 Testing wiring integrity 37
7.2 Connecting the RS232 PC serial link 37
7.3 Powering up the system 38
Chapter 8 Programming from the panel................................................ 40
Chapter 9 Preparing the programming data .......................................... 41
9.1 Set Time and date 41
9.2 Setting delays and times 41
9.3 Other options 41
9.4 Defining zones 42
9.5 Setting holidays 42
9.6 Setting the Timers 42
Chapter 10 Configuring the loop ........................................................... 44
10.1 Defining loop typology 44
10.2 Adding/Removing any type of device manually 44
10.3 Configuring the devices 45
10.4 Checking enrolled/addressed devices 45
Chapter 11 Programming fire detection points ........................................ 46
11.1 Programming fire-detection points 46
Chapter 12 Programming the extinguishant module................................. 49
12.1 Configuring the extinguishant module 50
12.2 Programming the module 50
12.3 Programming extinction points 51
Chapter 13 Configuring the devices connected to the RS485 BUS .............. 53
Chapter 14 Closing the programming session ......................................... 54
14.1 Restoring factory settings 54
Chapter 15 SmartLeague software ........................................................ 55
15.1 Overview 55
15.2 The Solutions 55
15.3 Enable programming via PC 55
Chapter 16 Maintenance ...................................................................... 56
16.1 View Events 56
16.2 Day/Night Mode 56
16.3 Bypassing a zone or point 57
16.4 Bypass Dialer output and supervised fault 57
16.5 Testing points and zones 57
16.6 Force the LEDs and point outputs 57
16.7 Set the date for the next maintenance session 58
16.8 Loop Diagnostics 58
Chapter 17 Diagnostics and fault solutions ............................................. 59
17.1 “Open I/O” fault 59
17.2 “Shorted I/O” fault 59
17.3 Loop fault 59
17.4 Testing the Loop 59
17.5 Repeater faults 60
17.6 Battery Fault 60
17.7 Other faults 60
Appendix A Enea series devices ............................................................ 61
Appendix B Argus Devices .................................................................... 64
Appendix C Apollo devices.................................................................... 67
Appendix D Order Codes ...................................................................... 71
