Via PC: select the loop -> Parameter Tab to select the type of protocol and wiring, select the icon and
select Re-address loop.
Once this operation is complete (which may take several minutes), the software programme will design a
layout of the loop wiring ishowing all the connected devices.
A.2 Reading the loop
This operation allows the system to learn the serial numbers of all the devices connected to the loop and
enroll the logic addresses (number between 1 and 240) assigned to them during the addressing phase.
Note: The loop reading phase can be carried out only on previously addressed loops, either via the control
panel or by means of an EITK-DRV loop driver.
From the panel: insert the jumper in programming-mode position, <key>, Programming,
Configuration, Loop, Ok, Loop parameters, then select INIM as the type of protocol
and 4 Wires as the wiring method by pressing Ok, Esc, Auto configure, Acquire
Once this operation is complete, a summary screen - indicating the total number of devices found - will be
shown. Ensure that the number of devices found corresponds to the number of devices actually installed.
Via PC: select the loop -> Parameter Tab to select the type of protocol and wiring, select the icon and
select Read loop.
Once this operation is complete (which may take several minutes), the software programme will design a
layout of the loop wiring ishowing all the connected devices.
A.3 Updating the loop
This operation must be carried out each time a device is replaced or added to the loop. After replacing or
adding devices to the loop, work through the following operations.
From the panel
Adding/Replacing a device: insert the jumper in the programming position, <key>, Programming,
Configuration, Loop, Ok, Add point, select the point and enter the serial number of the
new or replacement device.
Removing a device: insert the jumper in the programming position, <key>, Programming,
Configuration, Loop, Ok, Delete point, select the point, press Ok to confirm the
operation.
Via PC: select the loop from the tree structure, then select the icon followes by Update Loop.
Once this operation is complete (which may take several minutes), the software programme will show a
double layout which will allow you to compare the previously-saved loop configuration with the new one.
The part with changes will be highlighted.
In order to continue, you must accept all the highlighted changes and double-click on any icons which are
not green, or press the Accept All button) and press CONTINUE. A new addressing phase (which may
take several minutes) will transfer the new configuration to the control panel.
