2 Hardware / System Installation
2.1 System Overview
The INNOMAR SBP models described in this manual incorporate a parametric narrow-beam sub-
bottom profiler (SBP) with echo sounder functionality and consist of one topside unit and one
sub-bottom (SBP) transducer.
For the “compact” model there is an optional “sidescan extension” (transducer and software)
available, please see appendix A.11 on page 181 for details.
For the “light” and “standard” models there are “-plus” versions, which also incorporate a dual-
frequency sidescan sonar, please see appendix A.4 and A.6 for details. For the sake of simplicity
this manual refers to “light” or “standard” also for the “-plus” models as long as no special
sidescan functions are discussed.
The control and data acquisition PC is built in for the “light / -plus”, “standard / -plus” and “medium-
100” models. For the “smart” and “compact” models an external PC / laptop-PC / tablet-PC is
required. The operating system of the control-PC has to be Microsoft
®
Windows
®
for all models.
Technical Specifications / Required Connections
For detailed technical specifications, wiring diagrams, weights and dimensions as well as draw-
ings of the transducers, please see the appendix:
 INNOMAR SES “smart”: A.1 on page 161 and A.8 on page 175,
 INNOMAR SES “compact”: A.2 on page 163 and A.9 on page 177,
 INNOMAR SES “light”: A.3 on page 165 and A.9 on page 177,
 INNOMAR SES “light-plus”: A.4 on page 167 and A.9 on page 177,
 INNOMAR SES “standard”: A.5 on page 169 and A.9 on page 177,
 INNOMAR.SES “standard-plus”: A.6 on page 171 and A.9 on page 177,
 INNOMAR SES “medium-100”: A.7 on page 173 and A.10 on page 179,
 INNOMAR “sidescan extension”: A.11 on page 181,
!
Make sure to use the correct transducer model (first letter of transducer serial number);
using the wrong transducer type can seriously damage the topside electronics.
Innomar SES model
Transducer S/N starts with letter
“smart” “M” (or same S/N as the topside unit)
“compact”
,
“light”
“C”
(or same
S/N as the to
pside unit)
“standard” “A” (or same S/N as the topside unit)
“medium
-
100”
“E”
(or same S/N as the topside unit)
Transport Boxes for the Innomar SBP System Hardware
All items of the INNOMAR systems are shipped in strong transport boxes with anti-shock foam.
These boxes are fitted for all kind of transportation, including air- and sea shipping and should
be used during any transport and storage.
!
Before putting the system components back into the transport boxes after a survey,
make sure all items are cleaned and in dry condition.
During storage in dry environment keep the boxes open to allow air circulation.
