Preface
AC800 Series Intelligent Machine Controller Hardware User Guide
Preface
Thank you for purchasing the AC800 intelligent machine controller developed and manufactured
independently by Inovance.
Before using this product, carefully read this guide and the related manuals mentioned in this guide.
Note
◆
In the drawings of this guide, covers or casings may be removed to show the details of the equipment. Remember
to install the covers or casings as speci󶍾ed before working on the equipment.
◆
The drawings in the manual are shown for description only and may not match the product you purchased.
◆
The instructions are subject to change, without notice, due to product upgrade, speci󶍾cation modi󶍾cation as well
as e󶍽orts to increase the accuracy and convenience of the manual. The latest guide can be downloaded from our
website www.inovance.com.
◆
In case of any problem during use, contact our agents or customer service center. Customer service: 400-777-
1260, Email: UM@inovance.cn
Unpacking
The equipment is delivered with the following accessories:
1) A 3-pin plug for power wiring
2) Two 6-pin plugs for DI/DO and communication wiring
3) A user guide
If any of these items are missing or damaged, contact your dealer or sales representative immediately
Related Documents
Documents related to the controller are as follows:
AC800 Series Intelligent Machine Controller Hardware User Guide
AC800 Series Intelligent Machine Controller User Guide
Medium-sized PLC Software User Guide
Product Features
■ Appearance: Booksize all-metal design, with good heat dissipation and EMC performance.
■ Axis capacity: Dual EtherCAT bus interfaces supporting up to 256 axes, electronic cam and electronic gear.
■ Abundant motion control functions. Provides robot motion models and related function blocks, as
well as PTP, CNC, and CAM motion function blocks.
■ Information network: supports 2-channel 1 Gbps Gigabit Ethernet, ModbusTCP, and OPC UA Sever.
■ Expandability: 4-channel high-speed USB interface, supporting keyboard and mouse operation, and
development of other drivers. Support for multifunctional expansion cards to meet customized needs.
■ Maintenance: Field diagnosis through an LCD display, pluggable connectors, and replaceable fan and
battery.
■ Ease of use: Codesys-based IEC programming model platform, supporting various function libraries.
