BIOS Code Description
Process Code
0x98 Console input devices connect
0x99 Super IO Initialization
0x9A USB initialization is started
0x9C USB Detect
0x9D USB Enable
0xA0 IDE initialization is started
0xA2 IDE Detect
0xAD Ready To Boot event
0xAE Legacy Boot event
0xB2 Legacy Option ROM Initialization
0xB4 USB hot plug
Eorror code (when a BIOS error occurs, contact the manufacturer)
0x0E Microcode not found
0x0F Microcode not loaded
0x50 Memory initialization error. Invalid memory type or incompatible memory speed
0x51 Memory initialization error. SPD reading has failed
0x52 Memory initialization error. Invalid memory size or memory modules do not match
0x53
Memory initialization error. No usable memory detected
Note: If the buzzer sounds 6 times during startup, it means that the memory is installed improperly or
is not installed. Contact the manufacturer for a solution.
0x54 Unspeci󶍾ed memory initialization error
0x55 Memory not installed
0x56 Invalid CPU type or Speed
0x57 CPU mismatch
0x58 CPU self test failed or possible CPU cache error
0x59 CPU micro-code is not found or micro-code update is failed
0x5A Internal CPU error
0x5B reset PPI is not available
0x5C PEI phase BMC self-test failure
0xAB Setup Input Wait
0xD0 CPU initialization error
0xD1 North Bridge initialization error
0xD2 South Bridge initialization error
0xD3 Some of the Architectural Protocols are not available
0xD4 PCI resource allocation error. Out of Resources
0xD5 No Space for Legacy Option ROM
0xD6 No Console Output Devices are found
0xD7 No Console Input Devices are found
0xD8 Invalid password
0xD9 Error loading Boot Option (LoadImage returned error)
0xDA Boot Option is failed (StartImage returned error)
0xDB Flash update is failed
0xDC Reset protocol is not available
0xDD DXE phase BMC self-test failure
