Chapter 3 Mechanical and Electrical Installation
- 24 -
3.1.3 Mechanical Installation Method and Process
The CS200 has two housing types, plastic housing and sheet metal housing, according to different power classes.
The CS200 supports both surface mounting and embedded mounting (heatsink mounted outside the cabinet).
1. Surface mounting of the CS200 (plastic housing)
Figure 3-3 Surface mounting of the CS200 (plastic housing)
Install the AC drive from the
front of the control cabinet.
Back panel of
control cabinet
2. Embedded mounting of the CS200 (plastic housing)
Figure 3-4 External hanging bracket for the CS200 (plastic housing)
External bracket
